Tube OD: 5/16″ Tube Wall: 0.028″ Tube Length: 4 ft Surface: Copper Coated Packaging (From inside to outside): Straight cut, plastic film wrapped, woven plastic strip, bubble film, woven plastic strip Shipping: Airway cargo
OD 5/16″ Wall 0.028″ Copper Coated Bundy Tube Double Wall Brazed Steel Tubing Delivered Read Post »
0. FOREWORD 0.1 This Indian Standard was adopted by the Indian Standards Institution on 15 July 1976, after the draft finalized by the Steel Tubes, Pipes and Fittings Sectional Committee had been approved by the Structural and Metals Division Council. 0.2 There has been a long felt need for copper brazed steel tubes used specially in
Indian Standard – IS 8119 SPECIFICATION FOR COPPER BRAZED STEEL TUBING Read Post »
Many buyers are confused by names of the double wall and single wall Bundy tubes. Once a while one of our client who needed double wall Bundy tube, but the tubes he purchased from somewhere else were actually single wall tubes coated with copper both inside and outside. Buyers of Bundy tubes should firstly clearly
How to Tell Double Wall Bundy Tubes from Single Wall Bundy Tubes Read Post »
OD: 6.35mm, 1/4 inch Wall: 0.7mm, 0.028 inch Tube Structure: Bundy welded (double wall copper brazed) Surface Finish: copper plated inside and outside, 3 micro meter
6.35×0.7mm Copper Coated Double Wall Bundy Welded Tube Read Post »
Tube: double wall copper brazed steel tube (Bundy pipe) OD: 15mm Wall Thickness: 1mm Delivered Length: 6 meter Surface Finish: Zinc plated 13μm min, chromate treated to yellow/aurora color
15mm OD Yellow Zinc Plated Bundy Pipe 6 meter Long Read Post »
1. SCOPE This SAE Standard is intended to establish uniform methods for testing certain types of carbon steel and alloy steel tubing listed in 2.1.1. The specified test and performance criteria applicable to each variety of tubing are set forth in the respective SAE J Specifications. 2. REFERENCES 2.1 Applicable Publications The following publications form
SAE J1677 Tests and Procedures for Carbon Steel and Low Alloy Steel Tubing Read Post »
This standard is issued under the fixed designation A 254; the number immediately following the designation indicates the year of original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A superscript epsilon (e) indicates an editorial change since the last revision or re-approval.
ASTM A254 Standard Specification for Copper-Brazed Steel Tubing Read Post »
Low pressure gas/compressed natural gas tubes are made from single wall welded steel tubes, zinc plated and then coated with PVC to further isolate the atmospheric moisture. Tube: Single Wall ERW Steel Tube Size: OD 6 mm/8 mm, Wall 1 mm Surface Finish: Zinc plated + PVC Coating Protection Certification: ISO9001 & TS16949 20-30Mpa Pressure
Available for single wall ERW, and double wall brazed steel tubes. Copper coated both sides for double wall Bundy tube, while only outside or both sides optional for single wall ERW Bundy tubes.
OD： 3.18 mm – 15 mm Wall: 0.5mm – 1 mm Manufacture standard: China YB/T 4164 US ASTM A254, SAE J527 Japan JASO M101 Russia GOST 11249 India IS 8119 Read More…
Manufactured with extra annealing process to get stable and lower mechanical properties. OD: 3.18 mm, 1/4 inch Wall thickness: 0.7 mm, 0.028″ Elongation: >35%
3.18mm 1/8″ OD Double Wall Brazed Bundy Steel Tubing in Flat Coil – Soft Annealed Read Post »
The steering system of passenger cars includes steering booster, power steering pump, oil sump, and connecting tubes. Before the adoption of Bundy tubes, cold drawn steel tubes of Φ12×1 are used to connect the components. The allowable pressure of the fluid is 10MPa. The higher volume of the inside surface residue must be eliminated by
Application of Bundy Tubes in Car Steering System Read Post »
